0 to 100 KPa Pressure sensor (mA Output)

Specifications:

  • Range: 0~100kPa
  • MEMS technology, Solid-state reliability
  • Barb inlet pipe
  • Calibrated mV output
  • Temperature compensated
  • Working temp.: -30℃~+125℃(-22℉~+257℉)
  • Gage pressure type(Positive & Negative Pressure)
  • Easy to use and embed in OEM equipment
SKU: RDNA-363.8

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

767.00 (Inc. GST)
650.00 (+18% GST Extra)

In stock

In stock

15 People watching this product now!
  • Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today

Free

  • Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)​

Rs. 99

  • via Delhivery.com (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

  • via Delhivery.com (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:

Description

XGZP191 is a surface mounting pressure sensor based on CF Sensor silicon-glass based piezoresistive pressure sensor die. The sensor die is bonded on a substrate with a plastic cap and packaged in a 6-pin SIP housing. The built-in circuit calibrates and compensates the sensor’s zero output, full-scale output, temperature drift and other parameters, and generates a high-precision standard voltage output signal proportional to the supply voltage.

The small size and high reliability of integration make this sensor a simple and economical choice for high volume application in a variety of industries. With standard PIN interface, XGZP191 is easy for users to install by through-hole mounting.

The XGZP191 pressure sensor is intended for use with non-corrosive gas or air. It is highly prohibited to choke the side of pressure diaphragm during actual application. Please consult us if a pressure medium other then air is to be used.

Download Datasheet

Applications:

For medical and healthy equipment, e.g. Patient Monitoring, Infusion and Syringe Pumps, Anesthesia machines, Respirators and Ventilators, NPWT, DVT, Catheter, COPD Treatment, Kidney dialysis, Cupping & amp; Cosmetology, Hospital beds, Massage device etc.

For white goods and consumer electronics, e.g. Refrigerator, Printer, Humidifier, Washer/Dryer, Coffee machine, Dust collector or Cleaner, Robotic ,Sport equipment etc.

For more fields, e.g. Digital display meter, Air pump, Process control, Pressure switching, HVAC and pneumatic device, Air flow monitor, Automation, Automotive electronic, Intelligent fire control system etc.

Package Includes:

1 x 0 to 100 KPa Pressure sensor (mA Output)
