Specifications:

• Operating Voltage (VDC): 24Output
• Power (W): 200
• No-load Current (A): ≤3.6Motor
• Speed ±5% (RPM): 3250
• No-load Output Speed (RPM): 190
• Gear Ratio: 19 : 1
• Sound Level (dB(A)): ≤70Brake
• Torque (Nm): ≥33.4Gear
• Motor Rated Torque (Nm): 16.95
• Output Shaft OD (mm): 17 (with 6mm keyway and key)
• Weight: 15.5lbs per motor
• Efficiency : 80%

Specifications:

• Operating Voltage (VDC): 24
• Output Power (W): 200
• Dimensions (1) : 325mm
• Dimensions (2) : 82mm
• No-load Current (A): 3.6
• Motor Speed ±5% (RPM): 4400
• No-load Output Speed (RPM): 135
• Gear Ratio: 32 : 1
• Sound Level (dB(A)): 60
• Brake Torque (Nm): 33.4
• Gear Motor Rated Torque (Nm): 16.95
• Motor OD (mm): 79
• Output Shaft OD (mm): 17 (with 6mm keyway and key)
• Weight: 15.5lbs per motor
• Efficiency : 80%
