JK42BLS02 52W 24V 4000RPM 42mm Square Brushless Dc motor

  • Model No.: JK42BLS02
  • Number of Phase: 3phase
  • Number of Poles: 8poles
  • Rated Voltage: 24V
  • Rated Speed: 4000Rpm
  • Rated Torque: 0.12Nm
  • Rated Current: 3.3A
  • Rated Power: 77W
  • Peak Torque: 0.56Nm
  • Peak Current: 10.6A
  • Rotor Inertia: 48g.cm3
  • Body Length: 61mm
SKU: RDNA-215

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

2,124.00 (Inc. GST)
1,800.00 (+18% GST Extra)

Out of stock

Out of stock

16 People watching this product now!
  • Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today

Free

  • Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)​

Rs. 99

  • via Delhivery.com (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

  • via Delhivery.com (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:

Description

JK42BLS02 DC24V 4000rpm 52W 0.12N.m 3.3A Brushless DC Motor With Hall-sensor 3-phase Brushless BLDC Motor

Specification:

  1. Model No.: JK42BLS02
  2. Number of Phase: 3phase
  3. Number of Poles: 8poles
  4. Rated Voltage: 24V
  5. Rated Speed: 4000Rpm
  6. Rated Torque: 0.12Nm
  7. Rated Current: 3.3A
  8. Rated Power: 77W
  9. Peak Torque: 0.56Nm
  10. Peak Current: 10.6A
  11. Rotor Inertia: 24g.cm3
  12. Body Length: 61mm
  13. Sensor: Honeywell
  14. Insulation Class: B
  15. Degree of Protection: IP30
  16. Storage Temperature: -15~+70℃
  17. Operation Temperature: -15~50℃

Features :

  1.  The model is JK42BLS02
  2.  Metal body, strong hardness, exquisite workmanship, not easy to rust.
  3.  Pure copper motor, small resistance, better conductivity, high torque.
  4.  Bass design, no noise interference.
  5.  Can be used in Automation Equipment.

APPLICATION:

Medical equipment: medical pumps, stirring instruments, peristaltic pumps, biopharmaceutical equipment. Industrial equipment: winding machines, printing machines, robots, grinding, cutting, drilling, automatic conveying systems, automatic positioning systems, level control systems, electric actuators, electric valves, vending machines.

Package Includes :

1 x JK42BLS02 52W 24V 4000RPM 42mm Square Brushless Dc motor
