JK42BLS01 26W 24V 4000RPM 42mm Square Brushless Dc motor

Specification:

- Model No.: JK42BLS02
- Number of Phase: 3phase
- Number of Poles: 8poles
- Rated Voltage: 24V
- Rated Speed: 4000Rpm
- Rated Torque: 0.06Nm
- Rated Current: 1.18A
- Rated Power: 26W
- Peak Torque: 0.19Nm
- Peak Current: 5.4A
- Rotor Inertia: 24g.cm3
- Body Length: 41mm
- Sensor: Honeywell
- Insulation Class: B
- Degree of Protection: IP30
- Storage Temperature: -15~+70℃
- Operation Temperature: -15~50℃

SKU: RDNA-179

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

₹1,947.00 (Inc. GST)
₹1,650.00 (+18% GST Extra)

Out of stock

Compare

Add to wishlist

15 People watching this product now!

Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today

Free

Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)

Rs. 99

via Delhivery.com (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

via Delhivery.com (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:

Description

JK42BLS01 DC24V 4000rpm 26W 0.06N.m 1.18A Brushless DC Motor With Hall-sensor 3-phase Brushless BLDC Motor

Features :

The model is JK42BLS01
Metal body, strong hardness, exquisite workmanship, not easy to rust.
Pure copper motor, small resistance, better conductivity, high torque.
Bass design, no noise interference.
Can be used in Automation Equipment.

APPLICATION：

Medical equipment: medical pumps, stirring instruments, peristaltic pumps, biopharmaceutical equipment. Industrial equipment: winding machines, printing machines, robots, grinding, cutting, drilling, automatic conveying systems, automatic positioning systems, level control systems, electric actuators, electric valves, vending machines.
