DWIN 15inch Smart Capacitive Touchscreen Display


  • Model No: DMG10768C150-03WTC
  • Touch Type: Capacitive
  • Resolution: 1024×768
  • Interface: TTL/RS232
  • Grade: Commercial
  • Color: 16.7M Colors; 24 Bit
  • Dimensions: 351.1 mm (W) x 253.5 mm (H) x 26.0 mm (T)
  • Backlight: LED
  • Operating Voltage: 12 Volts
  • Operating Current: 250ma to 720ma
  • Working Temperature: -20 to 70°C

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%


30,090.00 (Inc. GST)
25,500.00 (+18% GST Extra)

Available on backorder

Available on backorder

18 People watching this product now!
  • Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today


  • Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)​

Rs. 99

  • via (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

  • via (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:


The Dwin’s DMG10768C150 is a 15 inch Smart HMI Display with Capacitive Touch. This smart UART TFT display module can be programmed using DWIN DGUS software.

DWIN 15.0″ Capacitive Smart display is very easy to use and integrate with your embedded circuit with a simple serial UART interface. DWIN Displays are high quality and cost effective smart HMI touchscreens. The DWIN DMG10768C150 15.0″ Smart Capacitive Touchscreen Display can easily be interfaced with microcontrollers & controller boards like Arduino Uno, Arduino Nano, Arduino Mega, ESP8266, ESP32, PIC Microcontrollers, 8051 family of microcontrollers, etc.

This Smart displays are based on T5/T5L ASIC chip which is a dual core high performance GUI Asic which supports DGUS & OS  development mode. DGUS is the abbreviation of a Graphic Application Service Software from DWIN Technology. It is an intelligent GUI software completely innovated by DWIN Technology, and a special software that is unique to DWIN Technology and is solidified in software. Using the DGUS Software tool you can design amazing GUI’s without writing a single line of code.

Datasheet for DMG10768C150-03WTC

Package Includes

1 x DWIN DMG10768C150 15.0″ Smart Capacitive Touchscreen HMI Display
