2 Channel 24V Relay Module 30A with Optocoupler Isolation Supports High and Low Triger with Guide Rail

Specifications:

Supply voltage(V): DC 24V
Quiescent Current (mA): 5mA
Maximum Operating Current: 190mA
Trigger Mode: High and low-level trigger
Load Voltage: DC 30V / AC250
Load Current: 30A
Relay Life: more than 100,000 times

SKU: RDNA-JK36.1

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

₹642.01 (Inc. GST)
₹544.07 (+18% GST Extra)

Only 2 left in stock

Compare

Add to wishlist

20 People watching this product now!

Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today

Free

Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)

Rs. 99

via Delhivery.com (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

via Delhivery.com (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:

Description

This is a 2 Channel Relay Module 30A with Optocoupler Isolation 24V that Supports High and Low Triggers for PLC Automation. It uses a high-power relay, the maximum control load DC 24V 30A / AC 250V 30A. In line with international safety standards, the control area and the load area with isolation slots. It comes with each optocoupler isolation and anti-interference ability.

Features:

Using a high-power relay, the maximum control load DC24V 30A / AC 250V 30A;
With each optocoupler isolation, anti-interference ability.
In line with international safety standards, the control area and the load area with isolation slots.
Each channel has a relay on the LED indication.
Product Applications: PLC automation equipment control, industrial system control, logistics network control, home intelligent product control, electronic enthusiasts to develop experiments, all kinds of circuit modification.

Packing List:

1 x 2 Channel Relay Module 30A with Optocoupler Isolation 24V Supports High and Low Triger with Guide Rail
