2 Channel 12V Relay Module Solid State High Level SSR DC Control 250V 2A with Resistive Fuse

Specifications:

Part Number: G3MB-202P
Power supply:12VDC/160mA
Switching Voltage (VAC):240@2A
Isolation: Phototriac

SKU: RDNA-55.17

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

₹289.00 (Inc. GST)
₹244.92 (+18% GST Extra)

Only 2 left in stock

Compare

Add to wishlist

17 People watching this product now!

Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today

Free

Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)

Rs. 99

via Delhivery.com (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

via Delhivery.com (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:

Description

This is a 2 Channel 12V Solid State Relay Module. A solid-state relay (SSR) is just what it sounds like; an IC that acts like a mechanical relay. They allow you to control high-voltage AC loads from lower-voltage DC control circuitry. They accomplish this by using infrared light as the ‘contact,’ a solid-state relay is really just an IR LED and a photo Triac sealed up into a little box. Solid-state relays have several advantages over mechanical relays.

A Solid State Relay is similar to 2 Channel 12V Relay Module Solid State High-Level SSR DC Control 250V 2A with Resistive to a mechanic relay where it can be controlled through a digital signal. Solid State Relay generates no noise and has a much longer lifespan compared to the traditional mechanic relay.

DC+: connected to VCC (Supply power according to relay voltage)
DC-: connected to GND
CH1: relay module signal trigger point (Effective high-level trigger)
CH2: relay module signal trigger point (Effective high-level trigger)

Packing List:

1 x 2 Channel 12V Relay Module Solid State High Level SSR DC Control 250V 2A with Resistive Fuse
