M12 4mm Proximity Sensors Inductive Type (PNP)

300.90 (Including GST)

255.00 ( + 45.90 GST)


  • Supply voltage:10-30V d.c.
  • Switching current:150mA
  • No load current:≤15mA
  • Switching frequency:1000Hz
  • Sensing distance:4.0mm
  • Housing type:M12
  • Ambient temperature:-25 to +70°C
  • Connection type:M12 4 pin plug

In stock

Purchase this product now and earn 3 Points!

SKU: RDNA-244 Category:

Share this product


This DC 6-36V M12 Inductive 4mm PNP-NO Proximity Sensor Switch is a component widely used in the automatic control industry for detecting, controlling, and non-contact switching. When the proximity switch is close to some target object, it will send out a control signal. When the metal approaches near-proximity switch sensing area, an Edy Current is induced in metal. Which in turn disturbs the magnetic field produced by the Inductive Proximity Sensor. This change is sensed by the sensor.

This inductive proximity switches can be non-contact, no pressure, no spark, quickly issued the electrical command. Accurately reflect the position and stroke movement mechanism. Positioning accuracy, operating frequency, service life. Easy to install and suitable for harsh environments. This 4mm proximity sensor can detect a variety of metals, miniature size, long life, low price, shielded type installation, anti-interference ability, 1mm detection distance, used for precise positioning of molds, precision machine tools, and robots.

Note: Color may vary according to stock.
