ICL8038 Sine/Triangular/Square Wave Signal Generator Module 10-300KHZ

Specifications:

Working voltage: + 12V ~ + 25V
Can output triangular wave, Square wave and sine wave.
Frequency range: 10HZ ~ 300kHz
Low distortion sine wave: 1%
Duty ratio range: 2% to 98%
Low temperature drift: 50ppm / ℃
Triangular wave output linearity: 0.1%

SKU: RDNA-25.1
