HLKRM04 - 5.5V 32Mb RAM 8Mb Flash UART Serial - Ethernet - WiFi Wireless Module 02

HLKRM04 - 5.5V 32Mb RAM 8Mb Flash UART Serial - Ethernet - WiFi Wireless Module 01

HLKRM04-5.5V 32Mb RAM 8Mb Flash UART Serial-Ethernet-WiFi Wireless Module

Specifications:

Brand: Hi-Link
Network standard: wireless IEEE 802.11n, IEEE 802.11g,IEEE 802.11b wired IEEE 802.3, IEEE 802.3u
Wireless transmission rate: 11n: maximum up to 150Mbps, 11g: maximum up to 54Mbps, 11b: maximum up to 11Mbps
Track numbers: 1-14
Frequency range: 2.4-2.4835G
Emission power: 12-15DBM
WIFI work mode: Client/AP/Router
WDS Function:Support WDS wireless bridge connection
Wireless security: Wireless MAC address filtering, Wireless security function switch, 64/128/152 bit WEP encryption, WPA-PSK/WPA2-PSK,WPA/WPA2 security mechanism
Network management: Remote Web management, Configuration file import and export, WEB software upgrade
Operating temperature: -20-70C
TCP/UDP connection: Max connection number>20
Operating humidity: 10%-90%RH
Serial baud rate: 50~230400bps
Storage temperature: -40-80C
Storage humidity: 5%-90%RH

SKU: RDNA-K2.42

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

₹1,652.00 (Inc. GST)
₹1,400.00 (+18% GST Extra)

In stock

Compare

Add to wishlist

20 People watching this product now!

Pick up from the RoboticsDNA Store in Pune / Dunzo

To pick up today

Free

Same Day Delivery in Pune

(Mon-Sat) (Please Place Order Before 1:30 PM)

Rs. 99

via Delhivery.com (Express Mode)

Our courier will deliver to the specified address

3-5 Days

Rs. 149

via Delhivery.com (Surface Mode)

Our courier will deliver to the specified address

4-7 Days

Rs. 69

Payment Methods:

Description

HLK-RM04 is a new low-cost embedded UART-ETH-WIFI module (serial port – Ethernet – Wireless network) developed by Shenzhen Hi-Link Electronic co., Ltd.This product is an embedded module based on the universal serial interface network standard, built-in TCP / IP protocol stack, enabling the user serial port, Ethernet, wireless network (wifi) interface between the conversions.

Through the HLK-RM04 module, the traditional serial devices do not need to change any configuration; data can be transmitted through the Internet network. Provide a quick solution for the user’s serial devices to transfer data via Ethernet.

Datasheet of HLKRM04

Tutorials

Packing List:

1 x HLKRM04 – 5.5V 32Mb RAM 8Mb Flash UART Serial – Ethernet – WiFi Wireless Module
